| cooling | 5,3 кВт |
|---|---|
| Heating | 5,35 кВт |
Specifications
| Data | Mode | Item | CH-S18FTXAM-GD |
| Capacity | cooling | kW | 5,3 |
| Capacity | heating | kW | 5,35 |
| Power supply | – | – | ~ 220-240В/50Hz/1ph |
| Rated consumption | cooling | kW | 1,582 |
| Rated consumption | heating | kW | 1,393 |
| Airflow | – | m³/h | 1000/850/760/650/580/520/450 |
| Sound level | IDU (m/a/mx) | dB(А) | 45/42/40/37/34/29/26/23 |
| Sound level | ODU | dB(А) | 56 |
| Refrigerant type | – | – | R32 |
| Dimensions: | IDU | mm | 993×311×222 |
| Package: | IDU | mm | 1055×385×298 |
| Dimensions: | ODU | mm | 802×555×350 |
| Package: | ODU | mm | 872×398×620 |
| Weight(net/gross) | IDU | kg | 12,5/15 |
| Weight(net/gross) | ODU | kg | 31,5/34 |
| Compressor type | – | – | Rotary |
| Drying | – | l/h | 1,9 |
| Temperature range | cooling | °С | `-15~50 |
| Temperature range | heating | – | `-25~30 |
| Refrigerant | – | kg | 0,85 |
| Liquid connection | – | mm/inch | 6,38/1/4″ |
| Gas connection | – | mm/inch | 12.7/1/2″ |
| Maximum height pipeline | – | m | 10 |
| Maximum leigth pipeline | – | m | 25 |
| Fixing distance | – | m | 512 |
