DAYTONA Series (GEN VI) CH-S09FTXD2-WP/SC/BL

Domestic heat pump. Adapted to work on heat in northern countries;
Temperature range of effective operation is from -25°С to +50°С;
A special work algorithm that ensures stable and efficient operation at low temperatures outside, heating of the compressor and tray, speed controller of the fan of the outdoor unit;
“I-Action” technology – smooth and stable operation of the compressor at ultra-low frequencies (1 Hz);
The highest class of energy efficiency. Energy-saving equipment according to type A+++ Class Energy Efficiency – GENERATON VI;
“CH 7-SKY Technology” – a complex filtering system based on seven filters of a wide range of action;
The innovative “DOUBLE SELF-CLEAN” technology allows the air conditioner to self-clean from dust, fungi, viruses and bacteria by the method of instant freezing and subsequent heating of the heat exchanger plates to + 57-58°C. The air conditioner is completely cleaned in 30 minutes. This saves time and money on service maintenance, and allows you to get healthy air;
Wi-Fi module, for the possibility of controlling the air conditioner through a Smartphone / Tablet (OS: Android, iOS);
Protecting your home from freezing: “+ 8°С” function. The air conditioner will maintain a temperature of + 8°C, which prevents the room from freezing and consumes a minimum of electricity;
The possibility of connecting a wired remote control with the ability of two-week programming and joining the BMS smart home system (OPTION).

cooling	2.70 (0.8-3.80) kW
Heating	3.00 (0.9-4.25) kW

D03b9bab4ca93b6cd1cf73fd4c0e4976

6168dc560b1a7d057a28f460fd9d257a

67530440776d6d63bf3e8570150db52d

7d62c0aafe994e55eb95b2229fe92638

58ffc7e310fa4bc308c1437403fec53d

70f64c7dcfcddcb9209666b613b1d7cd

A3fb04eaf72d7e7791efdf8ea8955e68

28d82d6eb611cbb775eb0bd7cb33b6ab

024869517b45360763934f62099feedc

Ac0e4808eee6304991e282cd2c77e05e

29ec8d5e13d1f5bd9060757c4a72fbe2

De3c84148762b6c54f169e7fc605be29

99619269506ce0620f8de0569dcc1f32

Capacity (Cold) (kW)	2.70 (0.8-3.80)
Capacity (Warm) (kW)	3.00 (0.9-4.25)
Electric power supply	220-240V/50Hz/1Ph
Rated input (Cold) (kW)	0.695 (0.1-1.30) 1,55(0,35-2,50)
Rated input (Warm) (kW)	0.70 (0.15-1.40)
Energy performance EER (kW/kW)	7.5 (А++)
Energy performance COP (kW/kW)	5,1(A+++)
Air productive capacity (m³/h)	390/420/440/470/540/570/610
Sound-pressure level (Indoor unit) (dB(A))	18/22/24/26/30/34/37
Sound-pressure level (Outdoor unit) (dB(A))	50
Type of refrigerant coolant	R32
Dimensions (Indoor unit) (mm)	940×365×284/889×294×212
Dimensions (Outdoor unit) (mm)	794×376×615/732×555×330
Weight (Indoor Unit) (kg)	11/13
Weight (Outdoor Unit) (kg)	23.5/26
Compressor type	rotor
Drainage (l/h)	1.69
Operational temperature range (Cooling) (°C)	-15..+43
Operational temperature range (Heating) (°C)	-25..+24
Gas charge volume (kg)	0,5
Liquid pipeline diameter (mm/inch)	6,38/1/4″
Gas pipeline diameter (mm/inch)	9.53/3/8″
Maximum pipeline level difference (m)	10
Pipeline maximum length (m)	15
